Editor

The editorConfig section defines the editor interface parameters.

actionLink

type: object

Specifies the data received from the document editing service using the onMakeActionLink event or the onRequestSendNotify event in data.actionLink parameter, which contains the information about the action in the document that will be scrolled to.

Example:

{
  action: {
    type: "bookmark",
    data: "bookmark_name",
  },
}

actionLink.action

type: object

The action object that defines what to scroll to in the document.

actionLink.action.type

type: "bookmark" | "comment"

The type of action in the document.

Example: "bookmark"

actionLink.action.data

type: string

The data associated with the action: the bookmark name or the comment ID.

Example: "bookmark_name"

callbackUrl

type: string | required

Specifies absolute URL to the document storage service (which must be implemented by the software integrators who use ONLYOFFICE Docs on their own server).

Example: "https://example.com/url-to-callback"

coEditing

type: object

Defines the co-editing mode and the possibility to change it. This parameter is used to apply the co-editing and viewing modes.

Example:

{
  "mode": "fast",
  "change": true
}

coEditing.mode

type: string | default: "fast"

The co-editing mode. Can be fast or strict.

note

In case mode setting is changed in the editor interface, it will be stored in the browser local storage and will overwrite any values sent as the editorConfig.coEditing.mode parameter.

Example: "fast"

coEditing.change

type: boolean | default: true

Defines if the co-editing mode can be changed in the editor interface or not.

Example: true

Coediting mode

createUrl

type: string

Defines the absolute URL of the document where it will be created and available after creation. If not specified, there will be no creation button. Instead of this field, you can use the onRequestCreateNew event.

Example: "https://example.com/url-to-create-document"

Create URL

fileChoiceUrl

type: string

Defines the URL of the file selection dialog opened in an iframe for inserting images, selecting documents for comparison, or choosing mail merge data sources. The URL can contain the {documentType} and {fileExt} placeholders, which will be replaced with the appropriate values (e.g., ImagesOnly, DocumentsOnly).

note

The {documentType} placeholder is required for the Image from Storage and Document from Storage buttons to appear.

Deprecated

Instead of this parameter, use the onRequestInsertImage, onRequestSelectDocument, or onRequestSelectSpreadsheet events.

Example: "https://example.com/filechoice?type={documentType}"

lang

type: string | default: "en"

Defines the editor interface language. Uses two-letter (de, ru, it, etc.) language codes.

note

To translate the editor interface into Portuguese (Portugal) or Chinese (Traditional, Taiwan) (these languages were added in version 7.2), you need to use the four-letter language codes - pt-PT or zh-TW, respectively. The two-letter pt language code sets Portuguese (Brazil) and the zh code specifies Chinese (People's Republic of China).

Supported language codes

Code	Language
`ar`	Arabic
`az`	Azerbaijani
`be`	Belarusian
`bg`	Bulgarian
`ca`	Catalan
`cs`	Czech
`da`	Danish
`de`	German
`el`	Greek
`en`	English
`es`	Spanish
`eu`	Basque
`fi`	Finnish
`fr`	French
`gl`	Galician
`he`	Hebrew
`hr`	Croatian
`hu`	Hungarian
`hy`	Armenian
`id`	Indonesian
`it`	Italian
`ja`	Japanese
`ko`	Korean
`lo`	Lao
`lv`	Latvian
`ms`	Malay
`nl`	Dutch
`no`	Norwegian
`pl`	Polish
`pt`	Portuguese (Brazil)
`pt-PT`	Portuguese (Portugal)
`ro`	Romanian
`ru`	Russian
`si`	Sinhala
`sk`	Slovak
`sl`	Slovenian
`sq`	Albanian
`sr`	Serbian (Latin)
`sr-Cyrl`	Serbian (Cyrillic)
`sv`	Swedish
`tr`	Turkish
`uk`	Ukrainian
`ur`	Urdu
`vi`	Vietnamese
`zh`	Chinese (Simplified)
`zh-TW`	Chinese (Traditional)

Example: "en"

location

type: string | default: ""

Defines the default measurement units. Specify us or ca to set inches.

Deprecated

Starting from version 8.2, please use the region parameter instead.

Example: ""

mode

type: "edit" | "view" | default: "edit"

Defines the editor opening mode. Can be either view to open the document for viewing, or edit to open the document in the editing mode allowing you to apply changes to the document data.

Example: "edit"

mergeFolderUrl

type: string

Defines the absolute URL to the folder for saving the mail merge result.

Deprecated

Instead of this parameter, use the onRequestSaveAs event.

Example: "https://example.com/url-to-merge-folder"

recent

type: object[]

Defines the presence or absence of the documents in the Open Recent... menu option.

Example:

[
  {
    "folder": "Example Files",
    "title": "exampledocument1.docx",
    "url": "https://example.com/exampledocument1.docx"
  }
]

recent.folder

type: string

The folder where the document is stored (can be empty in case the document is stored in the root folder).

Example: "Example Files"

recent.title

type: string

The document title that will be displayed in the Open Recent... menu option.

Example: "exampledocument1.docx"

recent.url

type: string

The absolute URL to the document where it is stored.

Example: "https://example.com/exampledocument1.docx"

region

type: string | default: "en-US"

Defines the default display format for currency and date and time (in the Spreadsheet Editor only). Is set using the four-letter (en-US, fr-FR, etc.) language codes.

note

If lang is defined and a matching regional setting exists, the default value is taken from the lang parameter. Otherwise, en-US is used.

Starting from version 8.2, this parameter also defines the default measurement units in all editor types. For the ...-US or ...-CA regions, inches are used by default if other values are not specified in the editorConfig.customization.unit parameter.

Supported regional settings

Code	Region
`ar-EG`	Arabic (Egypt)
`ar-SA`	Arabic (Saudi Arabia)
`az-Latn-AZ`	Azerbaijani (Latin, Azerbaijan)
`bg-BG`	Bulgarian (Bulgaria)
`cs-CZ`	Czech (Czech Republic)
`da-DK`	Danish (Denmark)
`de-AT`	German (Austria)
`de-CH`	German (Switzerland)
`de-DE`	German (Germany)
`el-GR`	Greek (Greece)
`en-AU`	English (Australia)
`en-GB`	English (United Kingdom)
`en-ID`	English (Indonesia)
`en-US`	English (United States)
`es-ES`	Spanish (Spain)
`es-MX`	Spanish (Mexico)
`fi-FI`	Finnish (Finland)
`fr-CH`	French (Switzerland)
`fr-FR`	French (France)
`hu-HU`	Hungarian (Hungary)
`id-ID`	Indonesian (Indonesia)
`it-CH`	Italian (Switzerland)
`it-IT`	Italian (Italy)
`ja-JP`	Japanese (Japan)
`ko-KR`	Korean (Korea)
`lv-LV`	Latvian (Latvia)
`nl-NL`	Dutch (Netherlands)
`pl-PL`	Polish (Poland)
`pt-BR`	Portuguese (Brazil)
`pt-PT`	Portuguese (Portugal)
`ru-RU`	Russian (Russia)
`sk-SK`	Slovak (Slovakia)
`sl-SI`	Slovenian (Slovenia)
`sr-Cyrl-RS`	Serbian (Cyrillic, Serbia)
`sr-Latn-RS`	Serbian (Latin, Serbia)
`sv-FI`	Swedish (Finland)
`sv-SE`	Swedish (Sweden)
`tr-TR`	Turkish (Turkey)
`uk-UA`	Ukrainian (Ukraine)
`vi-VN`	Vietnamese (Vietnam)
`zh-CN`	Chinese (Simplified)
`zh-TW`	Chinese (Traditional)

Example: "en-US"

saveAsUrl

type: string

Defines the absolute URL to the folder for saving files.

Deprecated

Instead of this parameter, use the onRequestSaveAs event.

Example: "https://example.com/url-to-save-folder"

sharingSettingsUrl

type: string

Defines the absolute URL to the document sharing settings page.

Deprecated

Instead of this parameter, use the onRequestSharingSettings event.

Example: "https://example.com/url-to-sharing-settings"

templates

type: object[]

Defines the presence or absence of the templates in the Create New... menu option.

Example:

[
  {
    "image": "https://example.com/exampletemplate1.png",
    "title": "exampletemplate1.docx",
    "url": "https://example.com/url-to-create-template1"
  }
]

templates.image

type: string

The absolute URL to the image for template.

Example: "https://example.com/exampletemplate1.png"

templates.title

type: string

The template title that will be displayed in the Create New... menu option.

Example: "exampletemplate1.docx"

templates.url

type: string

The absolute URL to the document where it will be created and available after creation.

Example: "https://example.com/url-to-create-template1"

Templates

user

type: object

Defines the user currently viewing or editing the document.

note


If you are subscribed to the onRequestUsers event and send an avatar using the setUsers method, the user.image field in the initialization config is not required. We especially don't recommend to specify this parameter if the avatar is sent in the base64 format and the initialization config is signed with JWT. In this case, the token will be too long.

Example:

{
  "group": "Group1,Group2",
  "id": "78e1e841",
  "image": "https://example.com/url-to-user-avatar.png",
  "name": "John Smith"
}

user.group

type: string

The group (or several groups separated with commas) the user belongs to.

Example: "Group1,Group2"

user.id

type: string

The identification of the user. The length is limited to 128 symbols. This information is stored and used to distinguish co-authors, indicate the author of the last changes when saving and highlighting history (in the list of changes), and count users with access for a license based on the number of users. We recommend using some unique anonymized hash. Do not use sensitive data, like name or email for this field.

Example: "78e1e841"

user.image

type: string

The path to the user's avatar.

Example: "https://example.com/url-to-user-avatar.png"

user.name

type: string

The full name of the user. The length is limited to 128 symbols.

Example: "John Smith"

customization

type: object

The editor customization section. See the standard branding and white label pages for available parameters.

embedded

type: object

The embedded mode configuration section. See the embedded page for available parameters.

plugins

type: object

The plugins configuration section. See the plugins page for available parameters.

Example

const config = {
  // ...
  editorConfig: {
    actionLink: {
      action: {
        type: "bookmark",
        data: "bookmark_name",
      },
    },
    callbackUrl: "https://example.com/url-to-callback",
    coEditing: {
      mode: "fast",
      change: true,
    },
    createUrl: "https://example.com/url-to-create-document",
    lang: "en",
    mode: "edit",
    recent: [
      {
        folder: "Example Files",
        title: "exampledocument1.docx",
        url: "https://example.com/exampledocument1.docx",
      },
    ],
    region: "en-US",
    templates: [
      {
        image: "https://example.com/exampletemplate1.png",
        title: "exampletemplate1.docx",
        url: "https://example.com/url-to-create-template1",
      },
    ],
    user: {
      group: "Group1,Group2",
      id: "78e1e841",
      image: "https://example.com/url-to-user-avatar.png",
      name: "John Smith",
    },
    customization: {
      // ...
    },
    embedded: {
      // ...
    },
    plugins: {
      // ...
    },
  },
};

const docEditor = new DocsAPI.DocEditor("placeholder", config);

The example.com is the name of the server where document manager and document storage service are installed. See the How it works section to find out more on ONLYOFFICE Docs service client-server interactions.
