TableHeaderCell

TableHeaderCell is the title of one column in a TableHeader, with its sort arrow and the handle that resizes it.

The Table README describes it in full.

Props

Property	Type	Description
column	TTableColumn	The column to render: its title, its sort field and callbacks, and the flags that shape the cell.
index	number	Position of the column, which becomes the cell's id column_<index>.
onMouseDown	(event: MouseEvent<Element, MouseEvent>) => void	Called when the resize handle is pressed.
resizable?	booleanundefined	Draws the resize handle at the end of the cell.
sorted	boolean	Direction of the sort; turning it off turns the arrow over.
sortBy	string	Field the table is sorted by; the column with the same sortBy keeps its arrow visible.
defaultSize?	numberundefined	Width in pixels the column returns to when the widths are reset.
sortingVisible	boolean	Shows the sort arrow and lets clicks on the title and the arrow sort the table.
tagRef?	ForwardedRef<HTMLDivElement> | ((node: HTMLDivElement) => void) | undefined	Ref attached to the cell when the column asks for it with withTagRef.
testId?	stringundefined	Value of the cell's data-testid attribute. Default: table-header-cell.

Stories

Default

The title of a column the table is not sorted by; hover it to see the arrow that sorts by this column, and change any other prop live in the Controls panel below.

Resizable

The short bar at the end of the cell is the handle a user drags to widen the column (resizable); here it only reports the press, since TableHeader does the resizing.

Sorted By This Column

The column the table is sorted by keeps its arrow on screen without a hover, so the user sees what the list is ordered by (sortBy matches the column's sortBy).

Without Sorting

A column that cannot sort: no arrow on hover and clicks on the title do nothing, for a list whose order is fixed (sortingVisible off).

With Unchecked Checkbox

A column with a select-all checkbox that nothing is ticked in yet shows only its title; the checkbox appears once a row is selected.

With Checked Checkbox

The select-all checkbox before the title once every row is selected (checkbox.value); a click on it calls checkbox.onChange.

With Indeterminate Checkbox

The same checkbox partly ticked, for a selection that covers some rows but not all (checkbox.isIndeterminate).

Short Column

A narrow column, such as a row number, keeps 12 pixels before its handle instead of 22, so the title is not cut off (isShort).
